AutoStop Mini Plus Export

A compact, brake performance tester that uses a multi-channel sensor to measure tri-axial deceleration of any type of vehicle, making it one of the most versatile brake testers on the market. Featuring a USB-C fast charger and a lithium battery that last up to 8 hours on a single charge, it also offers a built-in storage capacity for 200 test records, ensuring efficiency and convenience.

3 Easy Testing Steps with AutoStop Mini Plus Export:

STEP 1
Attach Mini Plus Export to the dashboard, center console or passenger seat so that the buttons and screen are clearly visible.

STEP 2
Turn on Mini Plus Export, accelerate the vehicle to the desired test speed and apply the brakes until the vehicle is stationary.

STEP 3
After the vehicle has come to a stop, Mini Plus Export evaluates, and displays forward, sideways and vertical deceleration, distance to stop and lateral deviation within the lane.

- Determines tri-axial deceleration, forward as well as sideways deceleration (lane change)
- Calculates and displays MFDD (Mean Fully Developed Deceleration) in accordance with the ECE R 13
- Simple 12 button operation via a tactile membrane pad
- Can be installed anywhere in the vehicle.
- Self-aligning by identifying its orientation at the beginning of each test.
- Lightweight (< 500grms) and compact (90 x 200 x 35mm) • LCD display
- Adjustable display control
- Automatic start function
- Automatic shut-off after 15 minutes to preserve battery life (over 24 hours running time)
- Built-in integrity check
- Built-in real time clock
- Calibration is internationally traceable through NATA.
- Calibration interval twenty-four months
- 12 months warranty • Internet support hotline for diagnostics
- Comprehensive after-sales service and assistance
- USB-C and Bluetooth interface
- Memory storage: 200 tests
MINI PLUS Export-GPS ADDITIONAL FEATURES:
- GPS or Glonass or Galileo positioning
- Receiver, providing longitude and latitude.
- Position acquisition time – 1 Min Maximum
- Software configurable
Optional features:
- Remote Bluetooth printer
- Rare Earth magnet motorbike kit
- PC download capability and graph.
- Rubber suction cup motorbike kit

Input:

Accelerometer: accuracy ±2%
Resolution 0.01g, non-linearity 0.2%, transverse sensitivity 2%

Output:

16 x 1 character LCD display

Power source:

Lithium Polymer Battery
Temperature Range-5ºC – 50ºC

Temperature Range:

-5ºC – 50ºC

Humidity:

25% – 85%, non-condensing 1.0 line/sec

Motorbikes, Light vehicles & Trucks (depends on state jurisdiction)

Product Downloads

Click here for product manuals and brochures.

AutoStop Mini Plus Export Brochure

Download Now!

Important Note: Bluetooth Printer is compatible with remote AutoTest Bluetooth Printer but check that you have the Bluetooth capability on your model, by calling our Service Team!
